Details
Name
Carlos Barbosa RodriguesRole
External StudentSince
01st October 2013
Nationality
PortugalContacts
222094106
carlos.b.rodrigues@inesctec.pt
2023
Authors
Rodrigues, C; Correia, M; Abrantes, J; Rodrigues, M; Nadal, J;
Publication
COMPUTER METHODS, IMAGING AND VISUALIZATION IN BIOMECHANICS AND BIOMEDICAL ENGINEERING II
Abstract
This study presents lower limb joint load comparison from subject specific musculoskeletal model simulation (MSK-MS) and direct measurements from instrumented implants on post-operative (PO) patients. A case study was considered for MSK-MS gait analysis of a 40-year-old healthy male with 70 kg and 1.86 m height. Reflective adhesive markers were applied on skin surface of selected anatomical points at right and left lower limbs. Orthostatic and dynamic acquisition on normal gait (NG), stiff-knee gait (SKG) and slow running (SR) was performed from ground reaction forces with two force plates at 2 kHz and trajectories of skin markers with eight-camera system at 100 Hz. Subject specific MSK-MS was performed using AnyGait and morphed Twente Lower Extremity Model (TLEM), matching the size and joint morphology of the stick-figure model. Over-determinate kinematic analysiswas performed, and motion equations solved with hard and soft constraints. Representative MSK-MS gait cycles were selected at NG, SKG and SR lower limb joint vertical force components at the hip, the knee, and the ankle normalized to body weight (JFz/BW). Internal joint direct measurements of four PO patients', 61-83 years, average weight 808 N and 1.71 m height, with telemetric Hip I (4-channel), Hip II (8-channel) and knee (9-channel) instrumented implants were selected from Orthoload database with comparable gait to NG, SKG and SR. Statistical measurements presented similar mean JFz/BW at right/left hip, knee, ankle MSK-MS and asymmetric peak values with dominant NG, SKG and SR different variances (p < 0.05). Direct JFz/BW measures contrasted NG with similar hip and knee mean and variance from SKG and SR with different mean and variance. Peak JFz/BW direct measurements presented higher hip and knee values on SR and NG than SKG, with higher values at the knee than the hip on NG and SKG, and the opposite on SR. Direct JFz/BW measurements presented at the hip and the knee lower values than their corresponding MSK-MS on NG, SKG and SR.
2022
Authors
Rodrigues, C; Correia, M; Abrantes, J; Rodrigues, MAB; Nadal, J;
Publication
XXVII BRAZILIAN CONGRESS ON BIOMEDICAL ENGINEERING, CBEB 2020
Abstract
This study presents principal component analysis (PCA) intra-subject variability of lower limb surface electromyography (sEMG) at different muscle stretch-shortening cycle (SSC). Several key steps are presented on the research of muscle force production for human in-vivo and noninvasive studies as well as on SSC contribution at gait, run, and jump with the need for separation of muscle and tendon behavior. Complexity and unpredicted multiple muscle actuation are highlighted with the need for extraction of PCA components from muscle stretch-shortening cycle sEMG, namely on lower limb stereotyped muscle patterns assessed on standard maximum vertical jump (MVJ). The purpose of this study is to apply PCA to sEMG linear envelopes of lower limb selected muscles at different MVJ, to detect lower number of components explaining maximum sEMG variability, representative of low dimensional signal control on muscles synergies. Different MVJ were assessed with subject specific PCA of lower limb sEMG during Counter Movement Jump (CMJ), Drop Jump (DJ), and Squat Jump (SJ). Intra-subject variability of sEMG PCA allowed the detection of two components explaining maximum variability with different profiles and muscle grouping at CMJ, DJ, and SJ. First component (PC1), representing larger signal variability, presented higher value at SJ and DJ than CMJ, with the need for a higher number of PC's to explain the same cumulative percentual variance at CMJ than DJ and SJ. Comparison with intra-subject linear (r) and cross-correlation (CCr) presented higher r and CCr at SJ and DJ than CMJ, with higher paired correlations at the muscles grouped on the same component. Comparison of intra-subject analysis with previous study on same subject single trial allowed subject-specific generalization of the preceding results.
2022
Authors
Rodrigues, C; Correia, M; Abrantes, J; Rodrigues, MAB; Nadal, J;
Publication
XXVII BRAZILIAN CONGRESS ON BIOMEDICAL ENGINEERING, CBEB 2020
Abstract
This study presents and applies in vivo lower limb frequency response analysis during standard maximum vertical jump (MVJ) with long and short counter movement (CM) and corresponding muscle stretch shortening cycle (SSC) for comparison without CM and SSC condition. The study makes use of algebraic relation at the frequency domain to obtain the response function from the input and output signals. Single-input/single-output (SI/SO) constant parameter linear system (CPLS) was applied with vertical ground reaction force (GRFz) input and center of gravity (CG) vertical displacement (Delta z) output, obtaining lower limb frequency response function during MVJ impulse phase. Piecewise linearity and limited input-output range of experimentally acquired GRFz and CG Delta z during MVJ impulse phase were assessed to confirm assumptions for CPLS application. Piecewise stationarity of the input and output signal was ensured by acquiring those signals on each MVJ type at similar conditions, guaranteeing experimental repetitions under statistical similar conditions on each CM. Different CM condition on each MVJ type were compared as regards to maximum vertical height, time period of the impulse phase, fundamental harmonic frequencies, convergence of the GRFz input and CG Delta z output Fourier series, their autospectral and cross-spectral density, as well as its input-output coherence, cross-spectrum gain factor, and phase of the frequency response function. Several differences were detected among CM condition, potentially contributing to explain differences on achieved performances at each CM and SSC.
2022
Authors
Rodrigues, C; Correia, M; Abrantes, J; Rodrigues, MAB; Nadal, J;
Publication
XXVII BRAZILIAN CONGRESS ON BIOMEDICAL ENGINEERING, CBEB 2020
Abstract
This study presents subject specific lower limb joint angular kinematic and dynamic analysis at time and frequency domain as well as joint mechanical work, power and dynamic stiffness assessment during normal gait, stiff knee gait and slow running for indicative range operation of personalized active gait aid device. Gait aid devices present increasing interest for the generalization of gait rehabilitation, as an answer to the growth demand of population with gait rehabilitation need, as well as the insufficient health care personnel. Nevertheless, the large costs and standardized equipment leave out many patients without gait rehabilitation, with the need for low cost, personalized gait rehabilitation equipment, based on subject-specific analysis. In vivo and noninvasive case study was assessed of a healthy male subject 70 kg mass and 1.86 m height on human gait lab. Reflective adhesive marks were applied at skin surface of lower limb selected anatomical points and images captured with eight 100 Hz camera Qualisys along with ground reaction forces and force moments acquired at 2000 Hz with two AMTI force plates during foot contact with the ground on normal gait (NG) at comfortable auto-selected velocity, stiff knee gait (SKG) with lower knee flexion and slow running (SR) at minimum run velocity on stiff knee condition. Inverse kinematics and dynamics were performed using AnyGait with TLEM model and lower limb joint angular signal analyzed. Indicative range operation from lower limb joint mechanical assessment were obtained at complementary domain for subject specific gait aid device selection and parametrization.
2022
Authors
Chaves, AC; Inocencio, AVM; Ferreira, KRC; Cavalcante, EL; Bispo, BC; Rodrigues, CMB; Lessa, PS; Rodrigues, MAB;
Publication
XXVII BRAZILIAN CONGRESS ON BIOMEDICAL ENGINEERING, CBEB 2020
Abstract
Population aging is a global reality, which can be characterized by morphological, psychological and functional changes. With the limitations resulting from the aging state, changes can occur in the performance of activities of daily living, such as decreased muscle strength, reduced bone mass, loss of flexibility and decreased capacity of the sensory system. Physiotherapy actively assists in the health promotion and prevention process, reducing the effects of the aging and improving the life quality. This paper has the objective of develop a movement monitoring device to assist in the rehabilitation of elderly people. The accelerometers or motion sensors, store data for long periods of time, providing information about the movement activities of the subjects over a desired period. These sensors are a useful tool in the assessment of physical activity. Through the data of accelerometer, it is possible to evaluate all type of physical activities. This is a pilot study composed by three steps: development, validation and application of the instrument. For the application and validation of this study, it was used a protocol of exercises, in order to capture the variations of the X, Y and Z axes of the accelerometers in each exercise. In the study, it was possible to identify the movements during the performance of the proposed protocol. Through he accelerometers position and the varying of his axes, it was possible to classify the exercises according to the number of repetitions and the time spent performing the exercise. In addition, it was possible to monitor remotely in real time by a physiotherapist. It is concluded that this device can assist in the management of elderly patients, assisting the health professional during the rehabilitation process.
